GATTA-Cells NIR
The GATTA-Cells NIR supplies you with high-quality standard cell slides with a labeled target in the near infrared (NIR) region. They are a perfect match for the new ZEISS LSM 980 with Airyscan 2 microscope.
Ready-to-use GATTA-Cells NIR slides contain fixed and stained huFIB cells for fluorescence imaging with labels in the region between 358 nm and 750 nm.
Currently we are offering one version:
GATTA-Cells 4C NIR
- Multicolor huFIB cells displaying 4 colors
- Nucleus: DAPI
- Mitochondria: Tom20 with Alexa Fluor 488
- Actin: Alexa Fluor 647
- Microtubules: α-Tubulin with Alexa Fluor 750
GATTA-Cells are embedded in ProLong Diamond and show high photo stability with shelf lifes of at least 6 months (storage at 2-8 °C).
product properties of GATTA-Cells NIR
| Type | GATTA-Cells 4C NIR |
|---|---|
| Cell type | huFIB |
| Fluorophores | DAPI, Alexa Fluor 488, Alexa Fluor 647, Alexa Fluor 750 |
| Embedding media | ProLong Diamond |
| Labeling | Intercalator, TOM20, Phalloidin, α-Tubulin |
| Level | Beginner |
| Price | 350,-€ |
Beginner: Samples to check the basic functions of your microscope. Easy to resolve, also for beginners in the field of super-resolution microscopy.
Advanced: Samples to optimize the settings of your microscope. Advanced experience is necessary in order to resolve the nanorulers.
Expert: Samples which demand perfectly aligned microscopes and very experienced users which are able to optimize acquisition and data evaluation.
fluorophore properties
| Fluorophore | Our notation |
Excitation / nm |
Emission / nm |
| Alexa Fluor 750 | NIR | 749 | 775 |
| Alexa Fluor 647 | R | 650 | 665 |
| Alexa Fluor 555 | Y | 555 | 580 |
| Alexa Fluor 488 | B | 488 | 525 |
| DAPI | UV | 358 | 461 |
Image Courtesy: Carl Zeiss Microscopy GmbH
