The GATTA-Cells NIR supplies you with high-quality standard cell slides with a labeled target in the green region. They are a perfect match for the new PicoQuant Luminosa microscope.
Ready-to-use GATTA-Cells NIR slides contain fixed and stained huFIB cells for fluorescence imaging with labels in the region between 532 nm with destinctive fluorescence life times.
Currently we are offering one version:
GATTA-Cells 3C FLIM
GATTA-Cells are embedded in ProLong Diamond and show high photo stability with shelf lifes of at least 6 months (storage at 2-8 °C).
Type | GATTA-Cells 3C FLIM |
---|---|
Cell type | U2OS |
Fluorophores | DAPI, Alexa Fluor 532, Alexa Fluor 555 |
Embedding media | ProLong Diamond |
Labeling | Intercalator, TOM20, α-Tubulin |
Level | Beginner |
Price | 350,-€ |
Beginner: Samples to check the basic functions of your microscope. Easy to resolve, also for beginners in the field of super-resolution microscopy.
Fluorophore | Our notation |
Excitation / nm |
Emission / nm |
Alexa Fluor 555 | G | 555 | 580 |
Alexa Fluor 532 | G | 534 | 553 |
DAPI | UV | 358 | 461 |
Image Courtesy: PicoQuant GmbH (Imaged on the PicoQuant Luminosa microscope with fastFLIM contrast and 532 nm laser excitation and a repition rate of 20 MHz. The detection part consist of a 530LP filter and an Excellitas SPAD)
